List of ADU events
98-150471-A02 Appendix G: System messages G-7
0A056-0 Antenna WARNING Xel DDM
warning
The cross-elevation motor controller has
temporarily observed an unusual situation
for temperature, voltage, current or
velocity. No user interaction required.
0A057-0 Antenna WARNING Ele DDM
warning
The elevation motor controller has
temporarily observed an unusual situation
for temperature, voltage, current or
velocity. No user interaction required.
0A058-0 Antenna WARNING PMM warning The polarisation motor controller has
temporarily observed an unusual situation
with regards to temperature, voltage,
current or velocity. No user interaction
required.
0A059-0 Antenna WARNING Azi cal. limits Check limits of the calibration result for the
azimuth axis are exceeded. Pointing
performance may be degraded. Info:
0x00000040: End stop detected before
expected limit 0x00000100: Zero width
is low 0x00000200: Zero width is high
0x00000400: Zero slack is high
0x00001000: Friction average is high
0x00002000: Friction peak is high
0x00004000: Friction asymmetry is high
Zero width low/high: Zero reference
module placement may be incorrect. Zero
slack high: Mechanical slack may be too
high. Friction average/peak high:
Mechanical friction is higher than expected.
Friction asymmetry high: Mechanical
imbalance may be too high.
0A05A-0 Antenna WARNING Xel cal. limits Check limits of the calibration result for the
cross-elevation axis are exceeded. Pointing
performance may be degraded. Info: See
0A059-0.
0A05B-0 Antenna WARNING Ele cal. limits Check limits of the calibration result for the
elevation axis are exceeded. Pointing
performance may be degraded. Info: See
0A059-0.
0A05C-0 Antenna WARNING Pol cal. limits Check limits of the calibration result for the
polarisation axis are exceeded. Pointing
performance may be degraded. Info: See
0A059-0.
Error code
(ID)
Unit Severity Description Explanation
Table G-1: ADU event messages (Continued)
SAILOR900HP.book Page 7 Monday, July 18, 2016 12:44 PM
