PacketCaptureConfigurationandSettings
D-Link UnifiedAccessPointAdministrator’sGuide
November2011 Page125
UnifiedAccessPointAdministrator’sGuide
PacketFileCapture
InPacketFileCapturemodetheAPstorescapturedpacketsintheRAMfilesystem.
Uponactivation,thepacketcaptureproceedsuntiloneofthefollowingoccurs:
•Thecapturetimereachesconfiguredduration
•Thecapturefilereachesitsmaximumsize
•Theadministratorstopsthecapture
Duringthecapture,youcanmonitorthecapture
status,elapsedcapturetime,andthecurrentcapturefilesize.
Thisinformationcanbeupdated,whilethecaptureisinprogress,byclickingRefresh.
Table49describesthefieldstoconfigurethepacketcapturestatus.
RemotePacketCapture
RemotePacketCaptureallowsyoutospecifya remoteportasthedestinationforpack etcaptures.Thisfeature
worksinconjunctionwiththeWiresharknetworkanalyzertoolforWindows.Apack etcaptureserverrunson
theAPandsendsthecapturedpacketsviaaTCPconnectiontotheWiresharktool.
A
WindowsPCrunningtheWiresharktoolallowsyoutodisplay,log,andanalyzecapturedtraffic.
Whentheremotecapturemodeisinuse,theAPdoesn'tstoreanycaptureddatalocallyinitsfilesystem.
YourcantraceuptofiveinterfacesontheAPatthesametime.Howe ver,you
muststartaseparateWireshark
sessionforeachinterface.YoucanconfiguretheIPportnumberusedforconnectingWiresharktotheAP.The
defaultportnumberis2002.Thesystemuses5consecutiveportnumbersstartingwiththeconfiguredportfor
thepack etcapturesessions.
Ifafirewallisinstalled
betweentheWiresharkPCandtheAP,theseportsmustbeallowe dtopassthroughthe
firewall.ThefirewallmustalsobeconfiguredtoallowtheWiresharkPCtoinitiateTCPconnectiontotheAP.
Table49:PacketFileCapture
Field Description
CaptureInterface SelectanAPCaptureInterfacenamefromthedrop‐downmenu.APcapture
interfacenamesareeligibleforpacketcaptureare:
• brtrunk‐LinuxbridgeinterfaceintheAP
•eth0‐802.3tr afficontheEthernetport.
•wlan0‐VAP0trafficonradio1.
•wlan1‐VAP0trafficonradio2.
•radio1‐802.11trafficon
radio1.
•radio2‐802.11trafficonradio2.
Note:TheDWL‐3600APhasonlyoneradio.Theavailableoptionsonthe
DWL‐3600APdonotincludewlan0orradio1.
CaptureDuration Specifythetimedurationinsecondsforthecapture(range10to3600).
MaxCaptureFileSize Specifythemaximumallowedsizefor
thecapturefileinKB(range64to4096).

D-Link DWL-3600AP Specifications

General

Frequency band	2.4 GHz
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	300 Mbit/s
Quality of Service (QoS) support	Yes
Data transfer rate	1 Gbit/s
Wireless technology	802.11 b/g/n
Antennas quantity	2
Antenna gain level (max)	4.7 dBi
Internal	No
Certification	FCC, CE
LED indicators	LAN, Power, WLAN
Interface	RJ-45
WAN connection	Ethernet (RJ-45)
Security algorithms	128-bit WEP, 64-bit WEP, SSID, WPA, WPA2
Storage temperature (T-T)	-20 - 65 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Power supply	8 W
Input current	2.5 A
AC input voltage	5 V

Weight and Dimensions

Weight	635 g
Dimensions (WxDxH)	203 x 203 x 48 mm
