D-Link DWL-3600AP User Manual

GettingStarted
D-Link UnifiedAccessPointAdministrator’sGuide
November2011 Page15
UnifiedAccessPointAdministrator’sGuide
Section2:GettingStarted
TheD‐LinkDWL‐x600APunifiedaccesspoint(UAP)providescontinuous,high‐speedaccessbetweenwireless
devicesandEthernetdevices.Itisanadvanced,standards‐basedsolutionforwirelessnetworkinginbusinesses
ofanysize.TheUAPenableswirelesslocalareanetwork(WLAN)deploymentwhileprovidingstate‐of‐the‐art

wirelessnetworkingfeatures.
TheUAPcanoperateintwomodes:StandaloneModeorManagedMode.InStandaloneMode,theUAPacts
asanindividualaccesspointinthenetwork,andyoumanageitbyusingtheAdministratorWebUserInterface
(UI),command‐lineinterface (CLI),orSNMP.InManagedMode
,theUAPispartoftheD‐LinkUnifiedWiredand
WirelessSystem,andyoumanageitbyusingtheD‐LinkUnifiedWirelessSwitch.IfanAPis inManagedMode,
theAdministratorWebUI,Telnet,SSH,andSNMPservicesaredisabled.
Thisdocumentdescribeshowtoperformthe
setup,management,andmaintenanceoftheUAPinStandalone
Mode.ForinformationaboutconfiguringtheAPinManagedModebyusingtheD‐LinkUnifiedWirelessSwitch,
seetheUserManualfortheswitch.
BeforeyoupoweronanewUAP,reviewthefollowingsectionstocheckrequiredhardwareand
software
components,clientconfigurations,andcompatibilityissues.Makesureyouhaveeverythingyouneedfora
successfullaunchandtestofyourneworextendedwirelessnetwork.
TheDWL‐6600APandDWL‐8600AParedual‐radioaccesspointsandsupporttheIEEE802.11a,802.11b,
802.11g,and802.11nmodes.TheDWL
‐3600APisasingle‐radioaccesspointandsupportstheIEEE802.11b,
IEEE802.11g,and802.11n(2.4GHz)modes.
Thissectioncontainsthefollowingtopics:
• “Administrator ’sComputerRequirements”
• “Wireles sClientRequirements”
• “DynamicandStaticIPAddressingontheAP”
• “InstallingtheUAP”
• “BasicSettings”
• “UsingtheCLItoViewthe
IPAddress”
• “ConfiguringtheEthernetSettings”
• “ConfiguringIEEE802.1XAuthentication”
• “VerifyingtheInstallation”
• “ConfiguringSecurityontheWirelessAccessPoint”
TomanagetheUAPbyusingtheWebinterfaceorbyusingtheCLIthroughTelnetorSSH,theAPneedsanIP
address.IfyouuseVLANsorIEEE802.1X
Authentication(portsecurity)onyournetwork,youmightneedto
configureadditionalsettingsontheAPbeforeitcanconnecttothenetwork.
Note:TheWLANAPisnotdesignedtofunctionasagatewaytotheInternet.ToconnectyourWLAN
tootherLANsortheInternet,youneedagatewaydevice.

D-Link DWL-3600AP Specifications

General

Frequency band	2.4 GHz
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	300 Mbit/s
Quality of Service (QoS) support	Yes
Data transfer rate	1 Gbit/s
Wireless technology	802.11 b/g/n
Antennas quantity	2
Antenna gain level (max)	4.7 dBi
Internal	No
Certification	FCC, CE
LED indicators	LAN, Power, WLAN
Interface	RJ-45
WAN connection	Ethernet (RJ-45)
Security algorithms	128-bit WEP, 64-bit WEP, SSID, WPA, WPA2
Storage temperature (T-T)	-20 - 65 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Power supply	8 W
Input current	2.5 A
AC input voltage	5 V

Weight and Dimensions

Weight	635 g
Dimensions (WxDxH)	203 x 203 x 48 mm
