D-Link DWL-3600AP User Manual

ManagingAccessPointsintheCluster
D-Link UnifiedAccessPointAdministrator’sGuide
November2011 Page151
UnifiedAccessPointAdministrator’sGuide
ThefollowingtabledescribestheconfigurationandstatusinformationavailableontheclusterAccessPoints
page.
Thefollowingtabledescribestheclusterinformationtoconfigureforanindividualmember.Theclustering
optionsareread‐onlywhenclusteringisenabled.Toconfiguretheclusteringoptions,youmuststopclustering.
RemovinganAccessPointfromtheCluster
Toremoveanaccesspointfromthecluster,dothefollowing.
1. GototheAdministrationWebpagesfortheclusteredaccesspoint.
TheAdministrationWebpagesforthestandaloneaccesspointaredisplayed.
2. ClicktheCluster>AccessPointslinkintheAdministrationpages.
3. ClickStopClustering.
Thechangewillbe
reflectedunderStatusforthataccesspoint;theaccesspointwillnowshowas
stand‐alone(insteadofcluster).
Table58:AccessPointsintheCluster
Field Description
Status Ifthestatusfieldisvisible,thentheAPisenabledforclustering.Ifclusteringisnotenabled,
thentheAPisoperatinginstand‐alonemodeandnoneoftheinformationinthistableis
visible.
TodisableclusteringontheAP,clickStopClustering.
Location Descriptionofwhere
theaccesspointisphysicallylocated.
MACAddress MediaAccessControl(MAC)addressoftheaccesspoint.
TheaddressshownhereistheMACaddressforthebridge(
br0).Thisistheaddressby
whichtheAPisknownexternallytoothernetworks.
IPAddress SpecifiestheIPaddressfortheaccesspoint.
EachIPaddressisalinktotheAdministrationWebpagesforthataccesspoint.Youcanuse
thelinkstonavigatetotheAdministrationWebpages
foraspecificaccesspoint.Thisis
usefulforviewingdataonaspecificaccesspointtomakesureaclustermemberispicking
upclusterconfigurationchanges,toconfigureadvancedsettingsonaparticularaccess
point,ortoswitchastandaloneaccesspointtoclustermode.
Table59:ClusteringOptions

Field Description
Location Enteradescriptionofwheretheaccesspointisphysicallylocated.
ClusterName EnterthenameoftheclusterfortheAPtojoin.
TheclusternameisnotsenttootherAPsinthecluster.Youmustconfigurethesame
clusternameoneachAPthatisamemberof
thecluster.Theclusternamemustbe
uniqueforeachclusteryouconfigureonthenetwork.
ClusteringIPVersion SpecifytheIPversionthattheAPsintheclusterusetocommunicatewitheach
other.

D-Link DWL-3600AP Specifications

General

Frequency band	2.4 GHz
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	300 Mbit/s
Quality of Service (QoS) support	Yes
Data transfer rate	1 Gbit/s
Wireless technology	802.11 b/g/n
Antennas quantity	2
Antenna gain level (max)	4.7 dBi
Internal	No
Certification	FCC, CE
LED indicators	LAN, Power, WLAN
Interface	RJ-45
WAN connection	Ethernet (RJ-45)
Security algorithms	128-bit WEP, 64-bit WEP, SSID, WPA, WPA2
Storage temperature (T-T)	-20 - 65 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Power supply	8 W
Input current	2.5 A
AC input voltage	5 V

Weight and Dimensions

Weight	635 g
Dimensions (WxDxH)	203 x 203 x 48 mm
