CreatingaDiffServClassMap
D-Link UnifiedAccessPointAdministrator’sGuide
November2011 Page139
UnifiedAccessPointAdministrator’sGuide
Figure42:ClientQoSDiffServClassMap
Table54:DiffServClassMap
Field Description
ClassMapConfiguration
ClassMapName EnteraClassMapNametoadd.Thenamecanrangefrom1to31
alphanumericcharacters .
MatchLayer3Protocol SpecifywhethertoclassifyIPv4orIPv6pack ets.
MatchCriteriaConfiguration
ClassMapName Selectnameoftheclasstoconfigure.
UsethefieldsintheMatch
CriteriaConfigurationareatomatchpacketstoa
class.Selectthecheckboxforeachfieldtobeusedasacriterionforaclassand
enterdataintherelatedfield.Youcanhavemultiplematchcriteriainaclass.
Note:Thematchcriteriafieldsthatareavailabledependon
whethertheclass
mapisanIPv4orIPv6classmap.
