VirtualAccessPointSettings
D-Link UnifiedAccessPointAdministrator’sGuide
November2011 Page76
UnifiedAccessPointAdministrator’sGuide
StaticWEPRules
IfyouuseStaticWEP,thefollowingrulesapply:
•AllclientstationsmusthavetheWirelessLAN(WLAN)securitysettoWEP,andallclientsmusthaveoneof
theWEPkeysspecifiedontheAPinordertode‐codeAP‐to‐stationdatatransmissions.
•TheAPmusthaveallkeys
usedbyclientsforstation‐to‐APtransmitsothatitcande‐codethestation
transmissions.
•Thesamekeymustoccupythesameslotonallnodes(APandclients).ForexampleiftheAPdefines
abc123keyasWEPkey3,thentheclientstationsmustdefinethatsame
stringasWEPkey3.
•Clientstationscanusedifferentkeystotransmitdatatotheaccesspoint.(Ortheycanallusethesame
key ,butthisislesssecurebecauseitmeansonestationcandecryptthedatabeingsentbyanother.)
•Onsomewirelessclientsoftware,youcan
configuremultipleWEPkeysanddefineaclientstation
“transferkeyindex”,andthensetthestationstoencryptthedatatheytransmitusingdifferentkeys.This
ensuresthatneighboringAPscannotdecodeeachother’stransmissions.
•Youcannotmix64‐bitand128‐bitWEPkeysbetweentheaccesspointand
itsclientstations.
IEEE802.1X
IEEE802.1Xisthestandarddefiningport‐basedauthenticationandinfrastructurefordoingkeymanagement.
ExtensibleAuthenticationProtocol( EAP)messagessentoveranIEEE802.11wirelessnetworkusingaprotocol
calledEAPEncapsulationOverLANs(EAPOL).IEEE802.1Xprovidesdynamically‐generate dkeysthatare
periodicallyrefreshed.AnRC4streamcipher
isusedtoencrypttheframebodyandcyclicredundancychecking
(CRC)ofeach802.11frame.
ThismoderequirestheuseofanexternalRADIUSservertoauthenticateusers.TheAPrequiresaRADIUS
servercapableofEAP,suchastheMicrosoftInternetAuthenticationServer.ToworkwithWindowsclients,
the
authenticationservermustsupportProtectedEAP(PEAP)andMSCHAPV2.
YoucanuseanyofavarietyofauthenticationmethodsthattheIEEE802.1Xmodesupports,including
certificates,Kerberos,andpublickeyauthentication.Youmustconfiguretheclientstationstousethesame
authenticationmethodtheAPuses.
Table24:
IEEE802.1X
Field Description
UseGlobalRADIUS
ServerSettings
BydefaulteachVAPusestheglobalRADIUSsettingsthatyoudefinefortheAPatthetop
oftheVAPpage.However,youcanconfigureeachVAPtouseadifferentsetofRADIUS
servers.
TousetheglobalRADIUSserversettings,makesurethe
checkboxisselected.
TouseaseparateRADIUSserverfortheVAP ,clearthecheckboxandentertheRADIUS
serverIPaddres sandkeyinthefollowingfields.
RADIUSIPAddress
Type
SpecifytheIPversionthattheRADIUSserveruses.
Youcantogglebetweentheaddresstypestoconfigure
IPv4andIPv6globalRADIUS
addresssettings,buttheAPcontactsonlytheRADIUSserverorserversfortheaddress
typeyouselectinthisfield.

D-Link DWL-3600AP Specifications

General

Frequency band	2.4 GHz
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	300 Mbit/s
Quality of Service (QoS) support	Yes
Data transfer rate	1 Gbit/s
Wireless technology	802.11 b/g/n
Antennas quantity	2
Antenna gain level (max)	4.7 dBi
Internal	No
Certification	FCC, CE
LED indicators	LAN, Power, WLAN
Interface	RJ-45
WAN connection	Ethernet (RJ-45)
Security algorithms	128-bit WEP, 64-bit WEP, SSID, WPA, WPA2
Storage temperature (T-T)	-20 - 65 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Power supply	8 W
Input current	2.5 A
AC input voltage	5 V

Weight and Dimensions

Weight	635 g
Dimensions (WxDxH)	203 x 203 x 48 mm
