D-Link DWL-3600AP User Manual

ConfiguringRADIUS‐AssignedClientQoSParameters
D-Link UnifiedAccessPointAdministrator’sGuide
November2011 Page147
UnifiedAccessPointAdministrator’sGuide
ConfiguringRADIUS‐AssignedClientQoSParameters
IfaVAPisconfiguredtouseWPAEnterprisesecurity,youcanincludeclientQoSinformationintheclient
databaseontheRADIUSserver.Whenaclientsuccessfullyauthenticates,theRADIUSservercaninclude
bandwidthlimitsandidentifytheACLsandDiffServpoliciestoapplytothespecificwirelessclient.ACLs
and
DiffServpoliciesreferencedintheRADIUSclientdatabasemustmatchthenamesoftheACLsandDiffServ
policiesconfiguredontheAPtobesuccessfullyappliedtothewirelessclients.
Table57describestheQoSattributesthatcanbeincludedintheclient'sRADIUSserverentry.Ifawireless
client
successfullyauthenticatesusingWPAEnterprise,eachQoSRADIUSattributethatexistsfortheclientis
senttotheAPforprocessing.Theattributesareoptionalanddonotneedtobepresentinthecliententry.If
theattributeisnotpres ent,theClientQoSsettingontheAPis
used.
ACLNameUp ShowsthenameoftheACLappliedtotrafficenteringtheAPintheinbound
direction.
WhenapacketorframeisreceivedbytheAP,theACL'srulesarecheckedfora
match.Thepacketorframeisprocessedifitispermittedanddiscardedifit
is
denied.
ACLTypeDown ShowsthetypeofACLtoapplytotrafficintheoutbound(AP‐to‐client)direction,
whichcanbeoneofthefollowing:
•IPv4:TheACLexaminesIPv4packetsformatchestoACLrules.
•IPv6:TheACLexaminesIPv6packetsformatchestoACLrules
•MAC:The
ACLexamineslayer2framesformatchestoACLrules
ACLNameDown ShowsthenameoftheACLappliedtotrafficintheoutbounddirection.
Afterswitchingthepack etorframetotheoutboundinterface,theACL'srulesare
checkedforamatch.Thepacketorframeis transmittedifit
ispermittedand
discardedifitisdenied.
DiffServPolicyUp ShowsthenameoftheDiffServpolicyappliedtotrafficsenttotheAPintheinbound
(client‐to‐AP)direction.
DiffServPolicyDown ShowsthenameoftheDiffServpolicyappliedtotrafficfromtheAPintheoutbound
(AP‐
to‐client)direction.
Table57:ClientQoSRADIUSAttributes
RADIUSAttribute ID Description Type/Range
Vendor‐Specific(26),
WISPr‐Bandwidth‐
Max‐Down
14122,8 Maximumallowedclientreceptionratefrom
theAPinbitspersecond.Ifnonzero,the
specifiedvalueisroundeddowntothenearest
64KbpsvaluewhenusedintheAP(64Kbps
minimum).Ifzero,bandwidthlimitingisnot
enforcedforthe
clientinthisdirection.
Type:integer
32‐bitunsignedinteger
value(0‐4294967295)
Table56:ClientQoSStatus(Cont.)
Field Description

D-Link DWL-3600AP Specifications

General

Frequency band	2.4 GHz
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	300 Mbit/s
Quality of Service (QoS) support	Yes
Data transfer rate	1 Gbit/s
Wireless technology	802.11 b/g/n
Antennas quantity	2
Antenna gain level (max)	4.7 dBi
Internal	No
Certification	FCC, CE
LED indicators	LAN, Power, WLAN
Interface	RJ-45
WAN connection	Ethernet (RJ-45)
Security algorithms	128-bit WEP, 64-bit WEP, SSID, WPA, WPA2
Storage temperature (T-T)	-20 - 65 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Power supply	8 W
Input current	2.5 A
AC input voltage	5 V

Weight and Dimensions

Weight	635 g
Dimensions (WxDxH)	203 x 203 x 48 mm
