ViewingRogueAPDetection
D-Link UnifiedAccessPointAdministrator’sGuide
November2011 Page42
UnifiedAccessPointAdministrator’sGuide
YoumustenabletheAPdetectiononaradioinordertocollectinformationaboutotherAPswithinrange.
Table12describestheinformationprovidedonneighboringaccesspoints.
Table12:RogueAPDetection
Field Description
APDetectionfor
Radio
ToallowtheAPradiostoperformneighborAPdetectionandcollectinformationabout
neighborAPs,clickEnabled.
TodisableneighborAPdetectionontheradios,clickDisabled.
IfyouchangetheAPdetectionmode,clickApplytosavethenewsettings.
DetectedRogueAPList
Action Click
GranttomovetheAPfromtheDetectedRogueAPListtotheKnownAPList.
Note:TheDetectedRougeAPandKnownAPlistsprovideinformation.TheDWL‐x600AP
doesnothaveanycontr olovertheAPs onthelistandcannotapplyanysecuritypolicies
toAPsdetectedthrough
theRFscan.
MAC ShowstheMACaddressoftheneighboringAP.
Radio TheRadiofieldindicateswhichradiodetectedtheneighboringAP:
•wlan0(RadioOne)
•wlan1(RadioTwo)
BeaconInt. ShowstheBeaconintervalbeingusedbythisAP.
BeaconframesaretransmittedbyanAPatregularintervalstoannouncetheexistenceof
thewirelessnetwork.Thedefaultbehavioristosendabeaconframeonceevery100
milliseconds(or10persecond).
TheBeaconIntervalissetontheRadiopage.(See“ModifyingRadioSettings”onpage58.)
Type Indicatesthetypeofdevice:
• APindicatestheneighboringdeviceisanAPthatsupportsthe
IEEE802.11Wireless
NetworkingFrameworkinInfrastructureMode.
• AdhocindicatesaneighboringstationrunninginAdhocMode.Stationssettoadhoc
modecommunicatewitheachotherdirectly,withouttheuseofatraditionalAP.Ad‐
hocmodeisanIEEE802.11WirelessNetworkingFrameworkalsoreferred
toaspeer‐
to‐peermodeoranIndependentBasicServiceSet(IBSS).
SSID TheServiceSetIdentifier(SSID)fortheAP.
TheSSIDisanalphanumericstringofupto32charactersthatuniquelyidentifiesawireless
localareanetwork.Itisalsoref erredtoastheNetworkName.
TheSSIDissetontheVAPpage.(See“ConfiguringLoadBalancing”onpage88.)
Privacy Indicateswhetherthereisanysecurityontheneighboringdevice.
• OffindicatesthattheSecuritymodeontheneighboringdeviceissettoNone(no
security).
• Onindicatesthattheneighboringdevicehassomesecurity
inplace.
SecurityisconfiguredontheAPfromtheVAPpage.
WPA IndicateswhetherWPAsecurityisonoroffforthisAP.

D-Link DWL-3600AP Specifications

General

Frequency band	2.4 GHz
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	300 Mbit/s
Quality of Service (QoS) support	Yes
Data transfer rate	1 Gbit/s
Wireless technology	802.11 b/g/n
Antennas quantity	2
Antenna gain level (max)	4.7 dBi
Internal	No
Certification	FCC, CE
LED indicators	LAN, Power, WLAN
Interface	RJ-45
WAN connection	Ethernet (RJ-45)
Security algorithms	128-bit WEP, 64-bit WEP, SSID, WPA, WPA2
Storage temperature (T-T)	-20 - 65 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Power supply	8 W
Input current	2.5 A
AC input voltage	5 V

Weight and Dimensions

Weight	635 g
Dimensions (WxDxH)	203 x 203 x 48 mm
