D-Link DWL-3600AP User Manual

UsingtheCLItoViewtheIPAddress
D-Link UnifiedAccessPointAdministrator’sGuide
November2011 Page24
UnifiedAccessPointAdministrator’sGuide
ConnectingtotheAPWebInterfacebyUsingtheIPv6 Address
ToconnecttotheAPbyusingtheIPv6globaladdressorIPv6linklocaladdress,youmustentertheAPaddress
intoyourbrowserinaspecialformat.
ToconnecttoanIPv6globaladdress,addsquarebracketsaroundtheIPv6address.Forexample,iftheAP
globalIPv6address
is2520::230:abff:fe00:2420,typethefollowingaddres sintotheIE7addressfield:http://
[2520::230:abff:fe00:2420].
ToconnecttotheiPv6linklocaladdress,replacethecolons(:)withhyphens(‐),addtheinterfacenumber
precededwithan"s,"thenadd".ipv6‐literal.net."Forexample,iftheAPlinklocaladdressis
fe80::230:abff:fe00:2420,and
theWindowsinterfaceisdefinedas"%6,"typethefollowingaddressintothe
IE7addressfield:http://fe80‐‐230‐abff‐fe00‐2420s6.ipv6‐literal.net.
UsingtheCLItoViewtheIPAddress
TheDHCPclientontheUAPisenabledbydefault.IfyouconnecttheUAPtoanetworkwithaDHCPserver,the
APautomaticallyacquiresanIPaddress.TomanagetheUAPbyusingtheAdministratorUI,youmustenterthe
IPaddressoftheaccesspointintoaWeb
browser.
IfaDHCPserveronyournetworkassignsanIPaddresstotheUAP,andyoudonotknowtheIPaddress,use
thefollowingstepstoviewtheIPaddressoftheUAP:
1. Usinganull‐modemcable,connectaVT100/ANSIterminaloraworkstationtotheconsole
(serial)port.
IfyouattachedaPC,Apple,orUNIXworkstation,startaterminal‐emulationprogram,suchas
HyperTerminalorTeraTerm.
2. Configuretheterminal‐emulationprogramtousethefollowingsettings:
•Baudrate:115200bps
•Databits:8
•Parity:none
•Stopbit:1
• Flowcontrol:none
3. Pressthereturnkey ,andaloginprompt
shouldappear.
Theloginnameisadmin.Thedefaultpasswordisadmin.Afterasuccessfullogin,thescreenshowsthe
(AccessPointName)#prompt.
Note:ThefollowinginstructionsandexamplesworkwithMicrosoftInternetExplorer7(IE7)and
mightnotworkwithotherbrowsers.

D-Link DWL-3600AP Specifications

General

Frequency band	2.4 GHz
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	300 Mbit/s
Quality of Service (QoS) support	Yes
Data transfer rate	1 Gbit/s
Wireless technology	802.11 b/g/n
Antennas quantity	2
Antenna gain level (max)	4.7 dBi
Internal	No
Certification	FCC, CE
LED indicators	LAN, Power, WLAN
Interface	RJ-45
WAN connection	Ethernet (RJ-45)
Security algorithms	128-bit WEP, 64-bit WEP, SSID, WPA, WPA2
Storage temperature (T-T)	-20 - 65 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Power supply	8 W
Input current	2.5 A
AC input voltage	5 V

Weight and Dimensions

Weight	635 g
Dimensions (WxDxH)	203 x 203 x 48 mm
