D-Link DWL-3600AP User Manual

EthernetSettings
D-Link UnifiedAccessPointAdministrator’sGuide
November2011 Page52
UnifiedAccessPointAdministrator’sGuide
Figure13:EthernetSettings
ThefollowingtabledescribesthefieldstovieworconfigureontheEthernetSettingspage.
Table17:EthernetSettingsPage
Field Description
Hostname EnterahostnamefortheAP.ThehostnameappearsintheCLIprompt.
Thehostnamehasthefollowingrequirements:
•Thelengthmustbebetween1–63characters.
• Upperandlowercasecharacters ,numbers,andhyphensareaccepted.
•Thefirstcharactermustbealetter(a–zorA–
Z),andthelastcharactercannotbea
hyphen.
MACAddress ShowstheMACaddressfortheLANinterfacefortheEthernetportonthisAP.Thisisa
read‐onlyfieldthatyoucannotchange.
ManagementVLAN
ID
ThemanagementVLANistheVLANassociatedwiththeIPaddressyouuse
toaccessthe
AP.ThedefaultmanagementVLANIDis1.
Provideanumberbetween1and4094forthemanagementVLANID.
UntaggedVLAN IfyoudisabletheuntaggedVLAN,alltrafficistaggedwithaVLANID.
BydefaultalltrafficontheUAPusesVLAN1,whichisthe
defaultuntaggedVLAN.This
meansthatalltrafficisuntaggeduntilyoudisabletheuntaggedVLAN,changethe
untaggedtrafficVLANID,orchangetheVLANIDforaVAPorclientusingRADIUS.
UntaggedVLANID Provideanumberbetween1and4094fortheuntaggedVLANID.Trafficon
theVLAN
thatyouspecifyinthisfieldwillnotbetaggedwithaVLANID.
ConnectionType IfyouselectDHCP,theUAPacquiresitsIPaddress,subnetmask,DNS,andgateway
informationfromaDHCPserver.
IfyouselectStaticIP,youmustenterinformationintheStaticIP
Address,SubnetMask,
andDefaultGatewayfields.

D-Link DWL-3600AP Specifications

General

Frequency band	2.4 GHz
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	300 Mbit/s
Quality of Service (QoS) support	Yes
Data transfer rate	1 Gbit/s
Wireless technology	802.11 b/g/n
Antennas quantity	2
Antenna gain level (max)	4.7 dBi
Internal	No
Certification	FCC, CE
LED indicators	LAN, Power, WLAN
Interface	RJ-45
WAN connection	Ethernet (RJ-45)
Security algorithms	128-bit WEP, 64-bit WEP, SSID, WPA, WPA2
Storage temperature (T-T)	-20 - 65 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Power supply	8 W
Input current	2.5 A
AC input voltage	5 V

Weight and Dimensions

Weight	635 g
Dimensions (WxDxH)	203 x 203 x 48 mm
