CreatingaDiffServPolicyMap
D-Link UnifiedAccessPointAdministrator’sGuide
November2011 Page144
UnifiedAccessPointAdministrator’sGuide
CreatingaDiffSer vPolicyMap
UsethePolicyMappagetocreateDiffServpoliciesandtoassociateacollectionofclasseswithoneormore
policystatements.
TheUAPsupportsupto50PolicyMaps.
Packetsareclassifiedandprocessedbasedondefinedcriteria.Theclassificationcriteriaisdefinedbyaclasson
theClassMappage.
Theprocessingisdefinedbyapolicy'sattributesonthePolicyMappage.Policyattributes
maybedefinedonaper‐classinstancebasis,anditistheseattributesthatareappliedwhenamatchoccurs.
APolicyMapcancontainupto10ClassMaps.Whenthepolicyis
active,theactionstakendependonwhich
classmatchesthepack et.
Packetprocessingbeginsbytestingtheclassmatchcriteriaforapacket.Apolicyisappliedtoapacketwhena
classmatchwithinthatpolicyisfound.
TocreateaDiffServpolicy,clickthePolicyMaptab.
Figure43:Client
QoSDiffServPolicyMap
