D-Link DWL-3600AP User Manual

CreatingaDiffServClassMap
D-Link UnifiedAccessPointAdministrator’sGuide
November2011 Page143
UnifiedAccessPointAdministrator’sGuide
TodeleteaClassMap,selecttheDeleteClassMapoptionandclickApply.
SourceMACMask EnterthesourceMACaddressmaskspecifyingwhichbitsinthedestination
MACtocompareagainstanEthernetframe.
Anfindicatesthattheaddressbitissignificant,anda0indicatesthatthe
addressbitistobeignored.AMACmaskofff:ff:ff:ff:ff:ffmatchesasingleMAC
address.
DestinationMACAddress SelectthisfieldandenterthedestinationMACaddresstocompareagainstan
Ethernetframe.
DestinationMACMask EnterthedestinationMACaddressmaskspecifyingwhichbitsinthe
destinationMACtocompareagainst
anEthernetframe.
Anfindicatesthattheaddressbitissignificant,anda0indicatesthatthe
addressbitistobeignored.AMACmaskofff:ff:ff:ff:ff:ffmatchesasingleMAC
address.
VLANID SelectthefieldandenteraVLANIDtobematchedforpackets.TheVLANID

rangeis0–4095.
IPv4ClassMaps
ServiceType Youcanspecifyonetypeofservicetouseinmatchingpack etstoclasscriteria.
IPDSCP TouseIPDSCPasamatchcriteria,selectthecheckboxandselectaDSCPvalue
keywordorenteraDSCP.
SelectfromList
Select
fromalistofDSCPtypes.
MatchtoValue
EnteraDSCPValuetomatch(0–63).
IPPrecedence Selectthisfieldtomatchthepacket'sIPPrecedenceva luetotheclasscriteria
IPPrecedencevalue.
TheIPPrecedencerangeis0–7.
IPTOSBits Selectthisfieldandenter
avaluetousethepacket'sTypeofServicebitsinthe
IPheaderasmatchcriteria.
TheTOSbitvaluerangesbetween(00–FF).Thehigh‐orderthreebitsrepresent
theIPprecedencevalue.Thehigh‐ordersixbitsrepresenttheIPDifferentiated
ServicesCodePoint(DSCP)value.
IP
TOSMask EnteranIPTOSmaskvaluetoperformabooleanANDwiththeTOSfieldinthe
headerofthepacketandcomparedagainsttheTOSenteredforthisrule.
TheTOSMaskcanbeusedtocomparespecificbits(Precedence/Typeof
Service)fromtheTOSfieldinthe
IPheaderofapacketagainsttheTOSvalue
enteredforthisrule.(00–FF).
DeleteClassMap Checktodeletetheclassmapselecte dintheClassMapNamemenu.Theclass
mapcannotbedeletedifitisalreadyattachedtoapolicy.
Table54:DiffServClassMap(Cont.)
Field Description

D-Link DWL-3600AP Specifications

General

Frequency band	2.4 GHz
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	300 Mbit/s
Quality of Service (QoS) support	Yes
Data transfer rate	1 Gbit/s
Wireless technology	802.11 b/g/n
Antennas quantity	2
Antenna gain level (max)	4.7 dBi
Internal	No
Certification	FCC, CE
LED indicators	LAN, Power, WLAN
Interface	RJ-45
WAN connection	Ethernet (RJ-45)
Security algorithms	128-bit WEP, 64-bit WEP, SSID, WPA, WPA2
Storage temperature (T-T)	-20 - 65 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Power supply	8 W
Input current	2.5 A
AC input voltage	5 V

Weight and Dimensions

Weight	635 g
Dimensions (WxDxH)	203 x 203 x 48 mm
