ConfigurationExamples

D-Link UnifiedAccessPointAdministrator’sGuide

November2011 Page164

UnifiedAccessPointAdministrator’sGuide

Appendix B: Configuration Examples

ThisappendixcontainsexamplesofhowtoconfigureselectedfeaturesavailableontheUAP.Eachexample

containsproceduresonhowtoconfigurethefeaturebyusingtheWebinterface,CLI,andSNMP.

Thisappendixdescribeshowtoperformthefollowingprocedures:

• “ConfiguringaVAP”

• “ConfiguringRadioSettings”

• “ConfiguringtheWirelessDistribution

System”

• “ClusteringAccessPoints”

• “ConfiguringClientQoS”

ForallSNMPexamples,theobjectsyouusetoAPareinaprivateMIB.Thepathtothetablesthatcontainthe

objectsisiso(1).org(3).dod(6).internet(1).private(4).enterprises(1).dlink(171).dlink‐products(10).dwl‐

ap(37).dwlWLANAP(26).

ConfiguringaVAP

ThisexampleshowshowtoconfigureVAP1withthefollowingnon‐defaultsettings:

•VLANID:2

• SSID:Marketing

•Security:WPAPersonalusingWPA2withCCMP(AES)

VAPConfigurationfromtheWebInterface

1. LogontotheAPandnavigatetotheManage>VAPpage.

2. IntheEnabledcolumnforVAP1,selectthecheckbox.

3. Enter2intheVLANIDcolumn.

4. IntheSSIDcolumn,deletetheexistingSSIDandtypeMarketing.

5. SelectWPAPersonalfromthemenuintheSecurity

column.

Additionalfieldsappear.

6. SelecttheWPA2andCCMP(AES)options,andcleartheWPAandTKIPoptions.

D-Link DWL-3600AP Specifications

General

Frequency band	2.4 GHz
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	300 Mbit/s
Quality of Service (QoS) support	Yes
Data transfer rate	1 Gbit/s
Wireless technology	802.11 b/g/n
Antennas quantity	2
Antenna gain level (max)	4.7 dBi
Internal	No
Certification	FCC, CE
LED indicators	LAN, Power, WLAN
Interface	RJ-45
WAN connection	Ethernet (RJ-45)
Security algorithms	128-bit WEP, 64-bit WEP, SSID, WPA, WPA2
Storage temperature (T-T)	-20 - 65 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Power supply	8 W
Input current	2.5 A
AC input voltage	5 V
