CreatingaDiffServClassMap
D-Link UnifiedAccessPointAdministrator’sGuide
November2011 Page141
UnifiedAccessPointAdministrator’sGuide
IPv6ClassMaps
SourceIPv6Address Selectthisfieldtorequireapacket'ssourceIPv6addresstomatchtheaddress
listedhere.EnteranIPv6addressintheappropriatefieldtoapplythiscriteria.
SourceIPv6PrefixLength EntertheprefixlengthofthesourceIPv6address.
DestinationIPv6Address Selectthisfieldto
requireapacket'sdestinationIPv6addresstomatchthe
addresslistedhere.EnteranIPv6addressintheappropriatefieldtoapplythis
criteria.
DestinationIPv6Prefix
Length
EntertheprefixlengthofthedestinationIPv6address.
IPv6FlowLabel Flowlabelis20‐bitnumberthatisuniquetoanIPv6
pack et.Itisusedbyend
stationstosignifyquality‐of‐servicehandlinginrouters(range0to1048575).
IPDSCP TouseIPDSCPasamatchcriteria,selectthecheckboxandselectaDSCPvalue
keywordorenteraDSCP.
SelectfromList
SelectfromalistofDSCP
types.
MatchtoValue
EnteraDSCPValuetomatch(0–63).
IPv4andIPv6ClassMaps
SourcePort Selectthisfieldtoincludeasourceportinthematchconditionfortherule.The
sourceportisidentifiedinthedatagramheader.
Onceyouselectthefield,choosetheport
nameorentertheportnumber.
SelectFromList
Selectthekeywordassociatedwiththesourceporttomatch:
•ftp
• ftpdata
•http
•smtp
•snmp
•telnet
•tftp
•www
Eachofthesekeywordstranslatesintoitsequivalentportnumber.
MatchtoPort
EntertheIANAportnumbertomatchtothesourceportidentifiedinthe
datagramheader.Theport
rangeis0–65535andincludesthreedifferenttypes
ofports:
•0–1023:WellKnownPorts
•1024–49151:RegisteredPorts
•49152–65535:Dynamicand/orPrivatePorts
Table54:DiffServClassMap(Cont.)
Field Description
