LIST OF TABLES (continued)
Table
Mk
Page
Fiche
Frame
6-1
Line Voltage Specifications
6-6-
3
E05
6-2
BMC Internal Cables
6-19
3
F04
6-3
CPU Chassis VNR Loopback Plugs
6-19
3
F04
6-4
CPU PCB Jumpers
6-23
3
F08
6-5
Baud Rate Jumper Switch (SW 1)
6-23
3
F08
6-6
Power-Up Self Test - Failed - XX Definitions
6-26
3
Fll
6-7
Device Codes
6-28
3
F13
6-8
System Modem Configuration Switch Settings
6-37
3
G08
6-9
Remote Modem Configuration Switch Settings
6-38
3
G09
