Datalogic Magellan 9400i User Manual

Ergonomic Recommendations
Product Reference Guide 23
Figure 10. Scanner and Scanner/Scale Models
Scanner Weights
When selecting materials and designing supports for scanner installation, don't
forget to factor in the weight of the scanner or scanner-scale and the products
that will need to be weighed or scanned during checkout.
Model Description
Scanner Weight
(w/o scale)
Scanner/Scale
Weight
939401 Short Shelf Mount Scanner 6.03 kg (13.3 lb) N/A
939403/
939404
Medium Shelf Mount Scanner 6.12 kg (13.5 lb) 7.39 kg (16.3 lb)
939405/
939406
Long Flange Mount Scanner 6.27 kg (13.82 lb) 7.53 kg (16.6 lb)
Model 939401
Short Scanner
Model 939403
Medium Scanner
Model 939405
Long Scanner
Model 939404
Medium Scanner/
Scale
Model 939406
Long Scanner/
Scale

Datalogic Magellan 9400i Specifications

General

Standard interfaces	USB
Connectivity technology	Wired
Type	Built-in bar code reader
Sensor type	Linear
Scanner type	1D/2D
Light levels (direct sunlight)	0 - 86080 lx
Linear (1D) barcodes supported	GS1 DataBar Expanded, GS1 DataBar Omnidirectional, JAN, U.P.C.
2D (matrix & stacked) barcodes supported	Aztec Code, Data Matrix, Micro QR Code, QR Code, Small Aztec Code
Input voltage	100 - 240 V
Input frequency	50 - 60 Hz
Power source type	AC
Power consumption (standby)	11 W
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
Product color	Black, Grey
Housing material	-
Sustainability certificates	RoHS

Weight and Dimensions

Depth	102 mm
Width	401 mm
Height	130 mm
Weight	- g
