Datalogic Magellan 9400i User Manual

Enter/Exit Programming Mode
Product Reference Guide 443
Micro QR Code Length 1, Length 2 Programming Instructions
If Micro QR Code Length Control is set to Fixed-Length decoding, this feature
specifies Micro QR Code first fixed length. If Micro QR Code Length Control is
set to Variable-Length decoding, this feature specifies the minimum label
length.
To set this feature:
1. Scan the ENTER/EXIT Programming Mode bar code.
2. Scan the bar code, Set Aztec Length 1 on page 446 or Set Micro QR Code
Length 2 on page 443 below. You’ll need to cover any unused bar codes
on this and the facing page to ensure that the scanner reads only the bar
code you intend to scan.
3. Scan the appropriate digits from the Keypad on page 461 in Appendix C
that represent the desired label length. The selectable range for this
option is 0001 to 3700. Pad all numbers with leading zeros to yield a four-
digit entry (0001-3700).
4. Complete the programming sequence by scanning the ENTER/EXIT Pro-
gramming Mode bar code.
NOTE
Length 1 is the minimum label length if in variable
length mode, or the first fixed length if in fixed length
mode. Length 2 is the maximum label length if in vari
-
able length mode, or the second fixed length if in fixed
length mode. Length includes the bar code's data char
-
acters only. Any value > 3700 will be considered to be
3700.
Default setting for this feature = 0001
Set Micro QR Code Length 1
Set Micro QR Code Length 2
Default setting for this feature = 0E74
042B(CR)
042C(CR)

Datalogic Magellan 9400i Specifications

General

Standard interfaces	USB
Connectivity technology	Wired
Type	Built-in bar code reader
Sensor type	Linear
Scanner type	1D/2D
Light levels (direct sunlight)	0 - 86080 lx
Linear (1D) barcodes supported	GS1 DataBar Expanded, GS1 DataBar Omnidirectional, JAN, U.P.C.
2D (matrix & stacked) barcodes supported	Aztec Code, Data Matrix, Micro QR Code, QR Code, Small Aztec Code
Input voltage	100 - 240 V
Input frequency	50 - 60 Hz
Power source type	AC
Power consumption (standby)	11 W
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
Product color	Black, Grey
Housing material	-
Sustainability certificates	RoHS

Weight and Dimensions

Depth	102 mm
Width	401 mm
Height	130 mm
Weight	- g
