Remote Scale Display — Verify that 0.00 lb (0.000 kg) is displayed, then place an
item on the weighing platter. Verify that the display shows a weight and
that the yellow LED goes out. Remove the item and observe that Remote
Scale Display shows 0.00 lb (0.000 kg) and that the yellow LED is On.
4. Unplug the AC power cord from the outlet and disconnect the power cord
and Remote Scale Display cable from the scanner’s connector panel.
After you have verified that the scanner and scale (if present) are completely
functional, continue with the following procedures.
Scale Diagnostic Mode
There is a diagnostic mode available to initiate scale diagnostic tests. Diagnos-
tic messages will be displayed on the Health & Status Indicator.
To enter Scale Diagnostic Mode, press the Scale Service Button (the same button
as ScaleSentry) for approximately four seconds. Six rapid tones will be sounded,
indicating the unit is leaving normal operation and entering Scale Diagnostic
Mode.
Health & Status Scale Diagnostics
Upon entering Scale Diagnostics, the Health & Status indicator
1
will then sound
one medium length beep and display a sequence of characters indicating the
following information:
NOTE
The scanner must be configured to allow Scale Diagnostic Mode. See
Programming on page 93 for details.
NOTE
This function does not apply to Adaptive Scale models.
1. The Remote Display (if one is present) can additionally display some scale diagnos-
tic information.
CHARACTERS EXPLANATION OF INDICATION
c x Where x is the number of calibrations performed to the scale.
x
Where x indicates the number of times the scale has been
zeroed.
Where x indicates the scale gravity zone.
- xxxx
Where xxxx is the load cell software checksum in hex lower 4
characters.
- x Where x indicates the scale software revision.
xxxx Data area reserved.
zzzz zzzz
Scale weighing package identifier and signal processing identi-
fier if present.
x
x
