40 Magellan™ 9300i / 9400i Scanners
If the diagnostics routine is not completed successfully, the scanner will sound
a series of tones and the Health & Status indicator will show an error code. Turn
to
Chapter 5, Problem Isolation for a description of error codes.
Press the Scale Zero Button once more to reset the unit and exit Scale Diagnos-
tic Mode. See the topic, Scanner and Scale Reset on page 55 in Chapter 3 for
more information about unit resets.
Optional Remote Display Scale Diagnostics Indications
If your unit is equipped with an optional Remote Display, it will show the fol-
lowing sequence, with each character being separated by 500ms or greater
blank time on the display (for ease of reading). This display continues to scroll
across the display for a set number of times.
u
customdata
Is the value of a custom data string (if present — no data may
be displayed if the item value is not set.
The sequence will be repeated
8
Upon successful completion, the scanner will automatically
reset, displaying an 8.
CHARACTERS EXPLANATION OF INDICATION
PASS or ERRx Where x is 1 through 5.
All segments on the display are illuminated.
Where x indicates the number of scale zeroing attempts.
c x
Where xx represents the number of calibrations, with a maxi-
mum of 999 displayed.
— x Where x indicates the scale gravity zone.
xxxx
Where xxxx is the load cell software checksum in hex lower 4
characters.
CHARACTERS EXPLANATION OF INDICATION
x
