ID-NET INTERFACE
ID-NET Cables
The following instructions are referred to Figure 58, Figure 59 and Figure 60.
• The general cable type specifications are: CAT5 twisted pair + additional CAT5
twisted pair, shielded cable AWG 24 (or AWG 22) stranded flexible.
We recommend using
DeviceNet cables (drop or trunk type) to the following refer-
ence standards:
AN50325 – IEC 62026
UL STYLE 2502 80°C 30V
• Cable Shield MUST be connected to earth ground ONLY at the Master.
• NEVER use ID-NET cable shield as common reference.
• The ID-NET max cable length depends on the baudrate used (see the Baudrate
Table below).
• For Common Power Connections use only 2 wires (ID+ and ID-).
- DC Voltage Power cable (Vdc – GND) should be handled as a signal cable (i.e. do
not put it together with AC cable):
- Wire dimensioning must be checked in order to avoid voltage drops greater than
0.8 Volts.
- Cable should lie down as near as possible to the ID-NET cable (avoiding wide
loops between them).
• Reader's chassis may be connected to earth.
• Network inside the same building.
* Application dependent, contact your Datalogic representative for details.
CBX100/500 Description
Shield Network Cable Shield
ID+ ID-NET Network Data +
ID- ID-NET Network Data -
REF Network Reference
Baudrate Table
Baudrate 125 kbps 250 kbps 500 kbps 1 Mbps
Cable Length 1200 m 900 m 700 m *
NOTE
The default ID-NET baudrate is 500 kbps. Lower ID-NET baudrates allow
longer cable lengths.
