MATRIX 320 (C-MOUNT) WITH 36 LEDS ILLUMINATOR
PRODUCT REFERENCE GUIDE
xvii
MATRIX 320 (C-MOUNT) WITH 36 LEDs ILLUMINATOR
Figure 4 - Matrix 320 C-Mount with 36 LEDs illuminator
1. HMI X-PRESS Interface 10. Bracket Mounting Holes (4)
2. Adapter 11. Ethernet Connector
3. Lens Cover 12. Power - COM - I/O Connector
4. Lens 13. Ethernet Connection LED
5. Red Spot 14. Power On LED
6. Green Spot 15. Compliance Label
7. Aiming System Laser Pointer 16. Avoid Laser Exit Point Label
8. Internal Illuminator 17. Device Class and Warning Labels
9. 360° Feedback
