MATRIX 320 RECOMMENDED ILLUMINATION
PRODUCT REFERENCE GUIDE 181
MATRIX 320 RECOMMENDED ILLUMINATION
In the following table these macro-cases are listed, each of them highlighting the most
suitable Matrix 320 lighting system used to resolve the application with a Standard
cover (STD.) with white/blue/red illuminator, a polarizer (PLZ.) with white/blue/red illu-
minator, and the LT-51x external red illuminator.
Legend:
Application
Characteristics
STD.
cover
with
white ill.
STD.
cover
with
blue ill.
STD.
cover
with
red ill.
PLZ.
cover
with
white ill.
PLZ.
cover
with
blue ill.
PLZ.
cover
with
red ill.
LT-51x
ext.
red ill.
Printed codes on opaque
paper or labels having a
flat surface
Laser Etching or Ink Jet
code marking on an
opaque, flat surface hav-
ing no evident machining
flaws
Code marking on an
opaque, rough surface
Code marking on a flat
surface with evident
machining flaws produced
by machining tools
Laser Etching or Dot
Peening code marking on
a flat, highly reflective sur-
face
Code marking on a curved
background
Red-printed code on white
background
Mixed color
codes/background
Havana background on
cardboard
Code under plastic film or
glossy surface with 0 skew
Suggested Compatible Not recommended
