Datalogic Matrix 320 Product Reference Guide

CBX ELECTRICAL CONNECTIONS
94 MATRIX 320
External Trigger Input Connections Using External Power
Figure 65 - PNP External Trigger Using External Power
Figure 66 - NPN External Trigger Using External Power
CBX100/500 Description
+V Power Source - External Trigger
I2A Input 2 A (polarity insensitive)
I2B Input 2 B (polarity insensitive)
-V Power Reference - External Trigger
