INTRODUCTION
46 MATRIX 320
MATRIX 320 C-MOUNT ASSEMBLY
Matrix 320 700-030 (C-Mount) can be assembled in two different configurations:
• Embedded illumination: base + lens + adapter + 36 LED illuminator
• External illumination: base + lens (+ long or short lens cover)
The following table shows the possible accessories for your assembly
1
.
For the possible combinations of illuminators and lenses, refer to "
Illuminators and
Lenses Combinations" on page 47
.
1. Refer to Accessories, starting on page 43 for other accessories such as cables, filters,
etc.
Accessory Description Order No.
C-Mount Lenses
LNM 000-021 LNM 000-021 CM 4MM VF1.8 1/2" ED 93ACC0285
LNM 001-031 LNM 001-031 CM 6MM VF1.85 1/2" ED 93ACC0286
LNM 003-021 LNM 003-021 CM 8MM VF1.8 1/2.5" ED 93ACC0287
LNM 005-021 LNM 005-021 CM 12MM VF1.8 1/1.8" ED 93ACC0288
LNM 007-021 LNM 007-021 CM 16MM VF1.8 1/1.8" ED 93ACC0289
LNM 009-031 LNM 009-031 CM 25MM VF1.85 1/1.8" ED 93ACC0290
LNM 010-011 LNM 010-011 CM 35MM VF1.65 1/1.8" ED 93ACC0292
C-Mount Lens Covers
Short Cover Lens Cover Lens and CM Base Short M320/P2 93ACC0279
Long Cover Lens Cover Lens and CM Base Long M320/P2 93ACC0280
Illuminator Kits: 36 LED illuminator + illuminator adapter (93ACC0281) + mounting bracket (93ACC0283)
KIT LTM 002-601 KIT LTM 002-601 S36L 60D WHT white 93ACC0356
KIT LTM 002-451 KIT LTM 002-451 S36L 45D WHT white 93ACC0357
KIT LTM 002-002 KIT LTM 002-002 S36L 120D BLU 475nm NL 93ACC0358
KIT LTM 002-602 KIT LTM 002-602 S36L 60D BLU 475nm 93ACC0359
KIT LTM 002-452 KIT LTM 002-452 S36L 45D BLU 475nm 93ACC0360
KIT LTM 002-352 KIT LTM 002-352 S36L 35D BLU 475nm 93ACC0361
KIT LTM 002-453 KIT LTM 002-453 S36L 45D IR 850nm 93ACC0363
KIT LTM 002-004 KIT LTM 002-004 S36L 130D UV 365nm NL 93ACC0364
36 LED Illuminators
LTM 002-601 LTM 002-601 S36L 60D WHT white 93ACC0298
LTM 002-351 LTM 002-351 S36L 35D WHT white 93ACC0306
LTM 002-002 LTM 002-002 S36L 120D BLU 475nm NL 93ACC0295
LTM 002-602 LTM 002-602 S36L 60D BLU 475nm 93ACC0299
LTM 002-452 LTM 002-452 S36L 45D BLU 475nm 93ACC0303
