GENERAL VIEW
xvi
MATRIX 320
MATRIX 320 (C-MOUNT) WITHOUT ILLUMINATOR
Figure 3 - Matrix 320 without illuminator
1. HMI X-PRESS Interface 6. Power On LED
2. Base Cover 7. Ethernet Connection LED
3. Lens Cover 8. Ethernet Connector
4. Lens 9. Power - COM - I/O Connector
5. Bracket Mounting Holes (4) 10. Compliance Label
