MATRIX 320 (LIQUID LENS) WITH 36 LEDS ILLUMINATOR
PRODUCT REFERENCE GUIDE xv
MATRIX 320 (LIQUID LENS) WITH 36 LEDs ILLUMINATOR
Figure 2 - Matrix 320 with 36 LEDs illuminator
1. HMI X-PRESS Interface 9. Bracket Mounting Holes (4)
2. Lens Cover 10. Ethernet Connector
3. Lens 11. Power - COM - I/O Connector
4. Red Spot 12. Ethernet Connection LED
5. Green Spot 13. Power On LED
6. Internal Illuminator 14. Device Class and Warning Labels
7. Aiming System Laser Pointer 15. Avoid Laser Exit Point Label
8. 360° Feedback

Datalogic Matrix 320 Specifications

General

Brand	Datalogic
Model	Matrix 320
Category	Barcode Reader
Language	English
