MATRIX 320 C-MOUNT ASSEMBLY
PRODUCT REFERENCE GUIDE 47
Illuminators and Lenses Combinations
The following table shows the optimal combinations of illuminators and lenses for
Matrix 320 C-Mount imager assembly.
LTM 002-352 LTM 002-352 S36L 35D BLU 475nm 93ACC0307
LTM 002-004 LTM 002-004 S36L 130D UV 365nm NL 93ACC0309
LTM 002-453 LTM 002-453 S36L 45D IR 850nm 93ACC0300
36 LED Illuminator Adapter
Adapter 36L Adapter LT to CM M320 93ACC0281
Accessory Description Order No.
Illuminator Models C-Mount Lens Focal Lengths (mm)
Description Order No. TIR Lens 4 6 8 12 16 25 35
LTM 002-601 S36L 60D WHT white 93ACC0298 YES
X X
LTM 002-351 S36L 35D WHT white 93ACC0306 YES
X X X
LTM 002-002 S36L 120D BLU 475nm NL 93ACC0295 NO
X X
LTM 002-602 S36L 60D BLU 475nm 93ACC0299 YES
X
LTM 002-452 S36L 45D BLU 475nm 93ACC0303 YES
X
LTM 002-352 S36L 35D BLU 475nm 93ACC0307 YES
X X X
LTM 002-004 S36L 130D UV 365nm NL 93ACC0309 NO
X X X X X X X
LTM 002-453 S36L 45D IR 850nm 93ACC0300 YES
X
