GENERAL VIEW
MATRIX 320 (LIQUID LENS) WITH 14 LEDs ILLUMINATOR
Figure 1 - Matrix 320 with 14 LEDs illuminator
1. Lens Cover 9. Bracket Mounting Holes (4)
2. HMI X-PRESS Interface 10. Ethernet Connection LED
3. Green Spot 11. Power - COM - I/O Connector
4. Red Spot 12. Ethernet Connector
5. Aiming System Laser Pointers 13. Power On LED
6. Internal Illuminator 14. Device Class and Warning Labels
7. Lens 15. Avoid Laser Exit Point Label
8. 360° Feedback

Datalogic Matrix 320 Specifications

General

Brand	Datalogic
Model	Matrix 320
Category	Barcode Reader
Language	English
