MATRIX 320 WITH MANUAL ADJUSTABLE FOCUS (C-MOUNT)

PRODUCT REFERENCE GUIDE

MATRIX 320 WITH MANUAL ADJUSTABLE FOCUS (C-

MOUNT)

Step 0B - Assemble the Reader

For Matrix 320 700-030 (C-Mount), the first step to perform is to assemble the accesso-

ries that make up the reader. Refer to

Matrix 320 C-Mount Assembly, starting on page 46

and Matrix 320 C-Mount Mounting Instructions, starting on page 68.

DL.CODE Illuminator Management Procedure

Step 1B - Connect the System

Refer to "Step 1A - Connect the System" on page 1.

Step 2B - Mount and Position the Reader

Refer to "Step 2A - Mount and Position the Reader" on page 3.

Step 3B - Focus the reader

To focus the reader, refer to Advanced Setup for Manual Adjustable Focus Models (C-

Mount), starting on page 22

, then place the reader at the factory focused Reading Dis-

tance and go to "

Step 4 - X-PRESS Configuration" on page 6.

1. Connect the reader to DL.CODE as

described in this chapter.

2. In the DL.CODE Device menu, click the

Settings > Settings > Maintenance Set-

tings > Current Illumintor Model item

and select the illuminator being used

from the list.

3. Click OK and at the device reset prompt

click Yes and wait until the device

resets. You can confirm by reopening

this item from the same menu.
