Datalogic Matrix 320 - Leds Illuminator

STANDARD ILLUMINATORS FOR SOFTWARE ADJUSTABLE FOCUS MODELS (LIQUID LENS)
PRODUCT REFERENCE GUIDE 175
36 LEDs Illuminator
Figure 101 - LED chains for 36 LEDs models
36 LEDs MODELS AND LED CHAIN CONFIGURATION
LIGHTS ON LEDs COLOR
All Chains White, Red, Blue
Top Left White, Red, Blue
Top Right White, Red, Blue
Left White, Red, Blue
Right White, Red, Blue
Bottom Left White, Red, Blue
Bottom Right White, Red, Blue
