110 MATRIX 320
CHAPTER 6
READING FEATURES
FOV CALCULATION
Use the data in the following table to calculate the FOV for your application, referring to
Figure 85 and the formula below.
* F/# = 6.1 for Red/Blue illuminator. For White illuminator, F/# = 6.5.
Model F/#
d
0
Offset
(mm)
Viewing
Angle
Horizontal
Viewing
Angle
Vertical
Viewing
Angle
Diagonal
Min Focus
Distance
(mm)
Max Focus
Distance
(mm)
Matrix 320 14L
LQL 9 mm
6.1* 22 34° 19° 39° 35 1000
Matrix 320 14L
LQL 16 mm
6.5 21 20° 11° 23° 70 1500
Matrix 320 36L
LQL 9 mm
6.1* 37 34° 19° 39° 35 1000
Matrix 320 36L
LQL 16 mm
6.5 36 20° 11° 23° 70 1500
Matrix 320
C-Mount 4mm
1.8 40.4 67.8° 41.4° 75.3° 0 1500
Matrix 320
C-Mount 6mm
1.8 41.1 48.3° 28.3° 54.4° 8.9 1500
Matrix 320
C-Mount 8mm
1.8 49.6 37.1° 21.4° 42.2° 0.4 1500
Matrix 320 C-
Mount 12mm
1.8 54.8 25.3° 14.4° 28.8° 45.2 2000
Matrix 320 C-
Mount 16mm
1.8 66 19.1° 10.8° 21.8° 134 2500
Matrix 320 C-
Mount 25mm
1.8 59 12.3° 6.9° 14.1° 141 2500
Matrix 320 C-
Mount 35mm
1.8 55 8.8° 4.9° 10.1° 154 2500
