Datalogic Matrix 320 Product Reference Guide

INTRODUCTION
40 MATRIX 320
X-PRESS Functions
Quick access to the following functions is provided by an easy procedure using the push
button:
1. Press the button (the Status LED will give a visual feedback).
2. Hold the button until the specific function LED is on (Test, Focus, Setup or Learn).
3. Release the button to enter the specific function.
Once button is pressed, the cycle of LEDs activation is as follows:
Test Mode
Once entered, the Bar Graph on the five LEDs is activated and if the imager starts read-
ing codes the Bar-Graph shows the Good Read Rate. The Bar Graph has the following
meaning:
In case of a NO READ condition, only the Status LED is on and blinks.
To exit the Test Mode, press the X-PRESS push button once.
NOTE
By default, the Test exits automatically after three minutes.
