Datalogic Matrix 320 Product Reference Guide

188 MATRIX 320
APPENDIX A
TECHNICAL FEATURES
ELECTRICAL FEATURES
Power
Matrix 320 with Software
Adjustable Focus
Matrix 320 with Manual
Adjustable Focus
Supply Voltage 24 Vdc ± 10%
Peak Supply Current 1 A max.
Without illuminator: 0.25 A max.
With illuminator
a
: 0.85 A max.
Average Supply Current
14 LEDs model: 0.42 A
36 LEDs model: 0.62 A
Without illuminator: 0.15 A
With illuminator: 0.52 A
Communication Interfaces
Main: RS232, RS422 Full-duplex 2400 to 115200 bit/s
Auxiliary: RS232 2400 to 115200 bit/s
ID-NET
Ethernet (Built-in)
supported application protocols
10/100/1000 Mbit/s
TCP/IP, UDP, FTP, EtherNet/IP,
Modbus TCP, PROFINET-IO
Inputs
Input 1(External Trigger) and Input 2 Opto-coupled and polarity insensitive
Max. Voltage 30 Vdc
Max. Input Current 10 mA
Outputs
b
Output 1, 2 and 3
NPN, PNP, or PP short circuit protected;
V
OUT
(I
LOAD
= 0 mA) Max.
24 Vdc
V
OUT
(I
LOAD
= 100 mA) Max.
3 Vdc
I
LOAD
Max.
100 mA
a. Peak supply current with white illuminator. Other available illuminators have the following peak supply current:
- Blue illuminator: 0.80 A
- IR illuminator: 0.55 A
- UV illuminator: 0.25 A
b. when connected to the CBX connection boxes the electrical features for Output 1 and 2 become the following:
Opto-isolated; V
CE
= 30 Vdc max.; I
CE
= 40 mA continuous max.; 130 mA pulsed max.;
V
CE saturation
= 1 Vdc max. @ 10 mA; P
D
= 90 mW Max. @ 50 °C ambient temp.
