Datalogic Matrix 320 Product Reference Guide

PRODUCT REFERENCE GUIDE 189
OPTICAL FEATURES
Matrix 320 with Software
Adjustable Focus
Matrix 320 with Manual
Adjustable Focus
Image Sensor CMOS
Image Format 2.0 Mpixel (1920 x 1080)
Frame Rate 60 frames/s
Pitch ± 35°
Tilt 0° - 360°
LED Safety according to EN 62471
Lenses Liquid Lenses
C-Mount Lenses
(4mm, 6mm, 8mm, 12mm,
16mm, 25mm, 35mm)
Aperture Angle
34° for Liquid Lens 9mm / 20° for
Liquid Lens 16mm
68°, 48°, 37°, 25°,
19°, 12°, 9°
Lighting System
Internal illuminator
(14 or 36 LEDs)
External or internal
illuminator (36 LEDs)
Reading Range
min. 0 mm, max. 2500 mm
Refer to "FOV Calculation" on page 110
Illumination
Internal illuminators with blue,
red, white lights
Internal illuminators with blue,
white, IR, UV lights
Aiming System Laser cross red projection aiming
Polarizing Filter Polarizing cover accessory
PHYSICAL FEATURES
Matrix 320
with Software Adjustable Focus
Matrix 320
with Manual Adjustable Focus
Matrix 320 with
14 LEDs illuminator
Matrix 320 with
36 LEDs illuminator
Matrix 320
without illuminator
Matrix 320
with illuminator
Dimensions
(with lens cover)
Connector at 0°
Connector at 90°
H x W x L
109 x 54 x 56 mm
(4.3 x 2.1 x 2.2 in)
88 x 54 x 76 mm
(3.5 x 2.1 x 2.1 in)
H x W x L
115.5 x 126 x 70 mm
(4.6 x 4.9 x 2.8 in)
101 x 126 x 91 mm
(4.6 x 4.9 x 2.8 in)
H x W x L
108.7 x 54 x 54.3 mm
(4.3 x 2.1 x 2.14 in)
88 x 54 x 54.3 mm
(3.5 x 2.1 x 2.14 in)
H x W x L
115.5 x 126 x 124.8 mm
(4.6 x 4.9 x 4.91 in)
101 x 126 x 138.2 mm
(4.6 x 4.9 x 5.44 in)
Weight
with lens and internal illuminator C-Mount base only Base+Adapter+Illuminator
380 g (13.4 oz) 640 g (22.6 oz)
300 g (10.6 oz) 900 g (31.7 oz)
Material
Aluminum

Datalogic Matrix 320 Specifications

General

Brand	Datalogic
Model	Matrix 320
Category	Barcode Reader
Language	English
