PRODUCT REFERENCE GUIDE 55
CHAPTER 3
INSTALLATION
PACKAGE CONTENTS
Verify that the Matrix 320 reader and all the parts supplied with the equipment are
present and intact when opening the packaging.
The list of parts for Matrix 320 7xx-330 and 7xx-430 includes:
• Matrix 320 reader
• Matrix 320 Quick Reference Guide
• Matrix 320 Heat Sink Mounting Instructions
• Test Charts (2)
• Mounting Kit
- Mounting Screws (4+3)
- Washers (4+3)
- Mounting Brackets (BK-32-000 Standard Fix Bracket for Matrix 320 with 14 LEDs
illuminator, BK-32-010 Pivot Fix Bracket for Matrix 320 with 36 LEDs illuminator)
• Heat sink (1)
The list of parts for Matrix 320 700-030 includes:
• Matrix 320 reader
• Matrix 320 C-Mount Quick Reference Guide
• Matrix 320 C-Mount Mounting Instructions
• Test Charts (2)
• Mounting Kit
- Mounting Screws (4+3)
- Washers (4+3)
- Mounting Brackets (BK-32-000 Standard Fix Bracket for Matrix 320 without illu-
minator, BK-32-010 Pivot Fix Bracket for Matrix 320 with 36 LEDs illuminator)
• Heat sink (1)
