TYPICAL LAYOUTS
104 MATRIX 320
When using a Local Area Network (LAN), one or more Matrix 320 readers can be con-
nected to the network by using CAB-ETH-X-M0x cables:
Figure 79 - Ethernet Network Layout
Host
CAB-DSxx-S
Matrix 320
CAB-ETH-X-M0x



Ethernet Interface
Auxiliary Serial Interface (RS232 - Data Monitor)
External Trigger (for One Shot or Phase Mode)
Alone



Alone Alone
CBX
CBX
Switch
Power
