INSTALLATION
66 MATRIX 320
3. Tighten two silver screws and two silver washers into the aligned holes to secure
the position. Finally tighten the central screw.
Figure 47 - Skew angle adjustment
NOTE
The particular distribution of the holes on the two brackets allows easy
adjustment of the skew angle in steps of 15°.
