AUSTROMAT
®
664 iSiC
®
/ 674 baSiC
2
5. User interface
Operating Instructions (Version 03/2018) 59
Closing the program editor
• Click [Save] to save the changes.
• Click on [Edit program]. A green field within the button goes dark to indicate that the
program editor is inactive. In addition, the "Edit" status in the information bar disappears.
CVTL commands
In particular, the CVTL commands execute the following functions:
• "A" defines the temperature in °C on the insulation table (Autodry),
• "C" defines the temperature in °C in the firing chamber (degrees Celsius)
• "V" defines the vacuum (Vacuum): Does not apply to the AUSTROMAT
®
664 and 674,
• "L" defines the lift position (Lift): L0 = Lift all the way down, L9 = Lift all the way up,
• "T" and at least a double-digit number define the time (Time) in seconds.
• "T" and a single-digit number define the number of audible signals,
• "T0xx.Cxxxx" defines a temperature ramp with the temperature gradient, T defines the
ramp in °C/min, C defines the end temperature in °C in the firing chamber,
• "T(x)xx.Cxxxx", (x) <> 0 defines a temperature ramp, T defines the time in s, C the end
temperature in °C in the firing chamber,
• "T(x)xx.Lx" defines a lift ramp, T defines the time in s, L the lift end position,
• "T0xx.Axxxx" defines a temperature ramp with the temperature gradient, T defines the
ramp in °C/min, A defines the end temperature in °C in the insulation table,
• "T(x)xx.Axxxx", (x) <> 0 defines a temperature ramp, T defines the time in s, A the end
temperature in °C on the insulation table,
• Two sequential commands can be separated by a space for clarity.
The syntax is checked when you confirm your entry. If the entered command line contains an
error, then a warning appears. In this case, correct for the command line.
Examples
Examples of programming are found in the download area of the DEKEMA website
(http://www.dekema.com
) or in the separate instructions for classic programming.
