Part II: Settings and Measurements
Chapter 14: Loopback Test
The Loopback Test function is a level test that only provides information on level loss in a loop. The levels
measured indicate RF levels measured at the input, as it is received.
The output signal generator (indicating the output level generated), minus the received level at the RF IN
port, indicates the signal loss in the loop under test.
