TEST ACTION APPLICABILITY
1 Note: The following list of items must be checked before continuing with
any no start tests.
The battery must be fully charged and in good condition. Alow charged battery may
produce invalid test results. If thebattery is low, charge thebattery and then attempt
to start the vehicle by cranking the engine for 15 seconds, 3 consecutive times.
This will allow any DTC’s to set that may have been erased due to a dead battery.
Ensure the Powers and Ground to the PCM are ok.
Make sure the PCM communicates with the DRBIIIt and that there are no DTC’s
stored in the PCM memory. If the PCM reports a No Response condition, refer to the
Communication category for the proper tests.
Read the PCM DTC’s with the DRBIIIt. If any DTC’s are present, they must be
repaired before continuing with any other No Start diagnostic tests. Refer to the
Symptom list for the related P-code that is reported by the PCM.
Ensure that the PCI bus is functional.Attempt to communicate with the Instrument
Cluster and SKIM, If you are unable to establish communicate refer to the
Communication category for the proper symptoms.
The Sentry Key Immobilizer System must be operating properly. Check for proper
communication with the DRBIIIt and check for DTC’s that may be stored in the
Sentry Key Immobilizer Module (SKIM). repair the DTC(s) before continuing.
If no DTC’s are found, using the DRBIIIt select Clear PCM (Batt Disconnect).
Crank the engine several times. Using the DRBIIIt, read DTC’s. If a DTC is present
perform the DTC diagnostics before continuing.
Were any problems found?
All
Yes → Repair as necessary.
Perform POWERTRAIN VERIFICATION TEST VER - 1.
No → Go To 2
2 Check for any open fuses in the PDC or Fuse Block that may be related to the No
Start condition.
Are any of the fuses open?
All
Yes → Using the wiring diagram/schematic as a guide, inspect the
wiring and connectors, repair as necessary. Replace the Fuse.
Perform POWERTRAIN VERIFICATION TEST VER - 1.
No → Go To 3
3 Turn the ignition on.
With the DRBIIIt, actuate the ASD Fuel System test.
Note: It may be necessary to use a mechanics stethoscope in the next step.
Listen for fuel pump operation at the fuel tank.
Does the Fuel Pump operate?
All
Yes → Go To 4
No → Go To 24
Caution: Stop All Actuations.
316
STARTING
*ENGINE CRANKS DOES NOT START — Continued
To Next Page
