Dodge 2004 Neon SRT4 Diagnostic Manual

TEST ACTION APPLICABILITY
4 NOTE: Repeat the following test at each Ignition wire. If spark is not
present or is weak on only one or two Ignition wires, the problem may be
the Ignition wire. Inspect all Ignition wires for proper operation.
Turn the ignition off.
Disconnect the #1 Ignition wire.
Connect a spark plug tester to the end of the Ignition wire.
While cranking the engine, observe the spark tester.
Is spark present?
All
Yes → Go To 5
No → Go To 9
5 Turn the ignition off.
WARNING: The fuel system is under a constant pressure even with the
engine off. Before testing or servicing any fuel system hose, fitting or line,
the fuel system pressure must be released.
Install a fuel pressure gauge.
Turn the ignition on.
With the DRBIIIt, actuate the ASD Fuel System test and observe the fuel pressure
gauge.
NOTE: Fuel pressure specification is 400 kPa +/- 34 kPa (58 psi +/- 5 psi).
Choose a conclusion that best matches your fuel pressure reading.
All
Below Specification
Go To 6
Within Specification
Go To 8
Above Specification
Replace the fuel filter/fuel pressure regulator.
Perform POWERTRAIN VERIFICATION TEST VER - 1.
Caution: Stop All Actuations.
6 Turn the ignition off.
WARNING: The fuel system is under a constant pressure even with the
engine off. Before testing or servicing any fuel system hose, fitting or line,
the fuel system pressure must be released.
Raise vehicle on hoist, and disconnect the fuel pressure line at the fuel pump module.
Install special 5/16 fuel line adapter tool #6539 between the disconnected fuel line
and the fuel pump module.
Attach a fuel pressure test gauge to the T fitting on the tool #6539
Turn the ignition on.
With the DRBIIIt, actuate the ASD Fuel System test and observe the fuel pressure
gauge.
NOTE: Fuel pressure specification is 400 KPa +/- 34 KPa (58 psi +/- 5 psi).
Is the fuel pressure within specification now?
All
Yes → Repair/replace fuel supply line as necessary.
Perform POWERTRAIN VERIFICATION TEST VER - 1.
No → Go To 7
Caution: Stop All Actuations.
317
STARTING
*ENGINE CRANKS DOES NOT START — Continued
