Troubleshooting
Operating Instructions 867 - 04.0 - 03/2018 139
2220 DA stepper card 2 not
responding
• Check connection cables
• Check LEDs of
DACextension box
• Software update
2221 DA stepper card 2 encoder
plug (Sub-D, 9-pin) not
connected
• Connect encoder cable to
the control, use correct
output
2222 DA stepper card 2 flywheel
position not found
• Check connection cables
• Check stepper motor 2 for
stiff movement
3103 Low voltage failure
(1
st
threshold)
Mains voltage < 180 V AC
• Check the mains voltage
• Stabilize the mains voltage
• Use generator
3108 Speed limited due to
insufficient mains voltage
• Check the mains voltage
3150 Maintenance necessary • Information on lubricating
the machine  Service
Instructions
3155 No release for sewing
process
• Parameter t5120-t5133 =
25
• Input signal for sewing
process release required
3160 Stitch loosening device • Stitch loosening cannot be
performed
3215 Bobbin stitch counter
(info value 0 reached)
• Change bobbin, set counter
value
• Press counter reset button
3216 Remaining thread monitor left • Change the left bobbin
3217 Remaining thread monitor
right
• Change the right bobbin
3218 Remaining thread monitor left
and right
• Change the left and right
bobbin
3223 Skip stitch detected
3224 Bobbin failed to rotate
Code Possible cause Remedial action

DURKOPP ADLER 867 Specifications

General

Stitch Type	Lockstitch
Max Stitch Length	12 mm
Needle System	134-35
Needle Thread Tension	Adjustable
Lubrication	Automatic
Type	Industrial Sewing Machine
Max Sewing Speed	3000 stitches per minute
Presser Foot Lift	20 mm
Power Requirements	230V/50Hz
