Page #145 background image
Troubleshooting
Operating Instructions 867 - 04.0 - 03/2018 143
1007 Error Error in the reference run Replace the encoder
Eliminate stiff
movement in the
sewing machine
1008 Error Encoder error Replace the encoder
1010 Error External synchronizer
plug (Sub-D, 9-pin) not
connected
Connect cable of
external synchronizer
to control; use correct
connection (Sync)
Only required for
machines with
transmission!
1011 Error Encoder Z pulse missing Switch off the control,
adjust the handwheel,
and switch the control
on again
If error is not corrected,
check encoder
1012 Error Synchronizer fault Replace the
synchronizer
1052 Error Sewing motor
overcurrent, internal
current increase >25 A
Check selection of
class
Replace the control
Replace sewing motor
Replace the encoder
1053 Error Sewing motor
overvoltage
Check selection of
class
Replace the control
1054 Error Internal short circuit Replace the control
1055 Error Sewing motor overload Eliminate stiff
movement in the
sewing machine
Replace the encoder
Replace sewing motor
Code
Error/
warning
Possible cause Remedial action
