DURKOPP ADLER 867 Durkopp Adler

Operation
Operating Instructions 867 - 04.0 - 03/2018 31
17. Insert the needle thread through the needle eye in such a way
that the loose thread end faces the hook.
For machines with a short thread cutter
18. Pull the needle thread through the needle eye until the loose
thread end has a length of approx. 4 cm with the thread lever (15)
at the highest position.
Important
Check the thread length.
If the loose thread end is too long, the needle thread may be caught
by the hook and cause a disturbance. If the loose thread end is
too short, the machine cannot start sewing.

DURKOPP ADLER 867 Specifications

General

Stitch Type	Lockstitch
Max Stitch Length	12 mm
Needle System	134-35
Needle Thread Tension	Adjustable
Lubrication	Automatic
Type	Industrial Sewing Machine
Max Sewing Speed	3000 stitches per minute
Presser Foot Lift	20 mm
Power Requirements	230V/50Hz
