DURKOPP ADLER 867 Durkopp Adler

Programming
Operating Instructions 867 - 04.0 - 03/2018 79
OP1000 buttons and functions
Button Function
Thread button group
Start bartack • Sets the start bartack
Multiple start bartack • Sets the multiple start
bartack
End bartack • Sets the end bartack
Multiple end bartack • Sets the multiple end
bartack
Thread cutter • Activates or deactivates
the thread cutter
Thread clamp • Activates or deactivates
the thread clamp
Needle position after
sewing stop
• Sets the needle position
after sewing stop
Sewing foot lift after
thread cutter
• Activates or deactivates
the sewing foot lift after
the thread cutter

DURKOPP ADLER 867 Specifications

General

Stitch Type	Lockstitch
Max Stitch Length	12 mm
Needle System	134-35
Needle Thread Tension	Adjustable
Lubrication	Automatic
Type	Industrial Sewing Machine
Max Sewing Speed	3000 stitches per minute
Presser Foot Lift	20 mm
Power Requirements	230V/50Hz
