DURKOPP ADLER 867 Durkopp Adler

Programming
80 Operating Instructions 867 - 04.0 - 03/2018
Sewing foot lift after
sewing stop
• Activates or deactivates
the sewing foot lift after
sewing stops
Soft start • Activates or deactivates
the soft start
Speed • Reduces the motor
speed
Function button • Activates or deactivates
any stored function
Programming button group
ESC • Ends parameter mode
A+ • Increases parameter
• Changes user level
• Selects subprogram
B+ • Increases parameter
• Changes to next higher
category
• Selects subprogram
C+ • Increases parameter
• Selects subprogram
D+ • Increases parameter
• Selects subprogram
Button Function

DURKOPP ADLER 867 Specifications

General

Stitch Type	Lockstitch
Max Stitch Length	12 mm
Needle System	134-35
Needle Thread Tension	Adjustable
Lubrication	Automatic
Type	Industrial Sewing Machine
Max Sewing Speed	3000 stitches per minute
Presser Foot Lift	20 mm
Power Requirements	230V/50Hz
