174 Universal Control Commands
For example, if g1=19 (decimal), the corresponding binary expression is
0010011. The pins fire in the following pattern:
The printer does not print until it receives sufficient data to fill all dot
columns reserved for graphics. Therefore, if dot column space is
reserved beyond the area in which printing occurs, it must be filled with
nulls (decimal 0s).
Cell
Values
Dot
Column
128
64
32
16
8
4
2
1
19 = 00010011
AB0-AG1
