Operator's Guide 291
GRAPHICS
ESC P (n) q (d1)..(dx) Graphics
ASCII
: ESC P (n) q (d1)..(dx)
Control
:
CTRL
[ P (n) q (d1)..(dx)
Decimal
: 27 80 (n) 113 (d1)..(dx)
Hexadecimal
: 1B 50 (n) 71 (d1)..(dx)
Causes the printer to print graphics dot columns.
n specifies the graphics density. This determines the horizontal dot-
column spacing, the
horizontal dots per inch, the horizontal overlap, the aspect ratio, the dot
columns per line, and the inches per line. The values for n are shown in
the tables below.
Graphics Densities
The table below assumes any pitch other than 12.0 or 6.0 set prior to
beginning graphics.
Dots/ Aspect Dots/ Inches/
(n) inch Overlap ratio line line
2 240 64.29% 3.36 3168 13.2
3 240 64.29% 3.36 3168 13.2
4 150 52.38% 2.08 1980 13.2
5, 0, or 1 120 40.48% 1.67 1584 13.2
6 100 28.57% 1.39 1320 13.2
7 100 28.57% 1.39 1320 13.2
8 75 04.76% 1.04 990 13.2
9 75 04.76% 1.04 990 13.2
