278 DEC LA210 Control Commands
LINES PER INCH
ESC [ (n) z Set Line Spacing
ASCII
: ESC [ (n) z
Control
:
CTRL
[[ (n) z
Decimal
: 27 91 (n) 122
Hexadecimal
:1B5B(n)7A
Sets the number of lines to be printed on each vertical inch (also called
vertical pitch). n specifies the line spacing as follows:
Lines Per Inch: 2 3 4 6 6 8 12
Value of n
ASCII
4560123
Decimal
52 53 54 48 49 50 51
Hexadecimal
34 35 36 30 31 32 33
6 lines per in. line spacing may also be set using ESC [ z, without sending
parameter n.
When the lines per inch setting is changed, the active line moves down
after the next vertical paper motion command to the next even multiple of
the new vertical pitch. The physical positions of the vertical tabs are also
altered. Changing lines per inch does not reset the top or bottom margin.
