Appendix A—
Specifications
The printer employs three printheads. Each printhead contains one row of
nine wires arranged vertically. The printheads are fastened to a shuttle or
carriage assembly.
Two carriage assemblies are offered:
•
Wide Carriage. In 10 pitch draft mode at 6 lpi, the wide carriage is
optimized to support a throughput of 300 lpm over 132 columns; in
NLQ mode, it supports a throughput of 75 lpm.
•
Narrow Carriage. In 10 pitch draft mode at 6 lpi, the narrow carriage is
optimized to support a throughput of 400 lpm over 80 columns; in NLQ
mode, it supports a throughput of 100 lpm.
Both models can print a 13.6-in. line of characters or graphics.
This appendix deals with specifications. These include the printer's
characteristics, safety features, reliability, physical features, and
requirements.
Note
: All specifications in this appendix are subject to change without
notice.
